COLOR-BAR, VOC GAS DETECTOR

MODEL C-21 WITH AUDIO ALARM &

DATA LOGGER OUTPUT



FOR DRY CLEANERS, PAINT SHOPS, PRINTERS, WOOD WORKERS, HOSPITALS, VEHICLE REPAIR FACILITIES, CHEMICAL PRODUCTION AREAS AND WHEREVER INDOOR AIR QUALITY MONITORING IS REQUIRED.



BENEFITS

• The Spectrex Model C-21 GAS DETECTOR helps you comply with the new VOC air quality regulations for hydrocarbon gases and solvent vapors
• Constantly monitors your work environment. Detects leaks and poor
• air quality before they are a health hazard
• No installation, simply plug it in. Easily used and understood by non-technical personnel
• Virtually no maintenance
• 24 hour per day, 7 day per week guarding for leaks. Beeper will sound when preset level of contamination is reached.



FEATURES

• Highly sensitive to solvent vapors and other VOCs. Bright green-yellow-red display clearly shows hazard level of gas or vapor

Typical color indications for PERCHLOROETHYLENE:

• Detects down to OSHA, EPA, and other regulatory-mandated levels... typically at low ppm concentrations
• Has built-in rechargeable battery for portable use. (This allows 2 hours in the unplugged mode to track down a leak)
• Access jack to external alarm and data logger
• Rugged construction with many safety features
• Heated semiconductor sensor
• Made in USA.



SAFETY FEATURES

Enclosure: Self extinguishing ABS plastic

Sensor: Healed element is flame arrestor protected

Electrical: (a) Circuits operate at 12 volts/25Oma. or less with no high capacity inductors or capacitors. (b) Automatically resetting fuse to protect against excess

current flow and excess heating. (c) Dual zener-type diode barrier to protect against surges, spikes, over-voltage, and reverse polarities





SPECIFICATIONS

• Response time: within a few seconds of gas reaching sensor
• Size: 3¼" x 1 3/8" x 2 3/8" (85 x 35 x 60mm)
• Weight: 5 oz. (140 grams.)
• Battery Life: Approx. 2 hours
• Power requirements: 120v, AC, self-contained Ni-Cad battery, or 12v DC in vehicles
• Measurement principle: Heated semiconductor sensor

GASES AND VAPORS THE C-21 WILL DETECT:



The above listing Is only a partial one, with materials actually run In our laboratory,
Detection threshold is typically at or below the OSHA established limits.
